DA55D

The use of a constant-bleed regulator improves pressure stability.
In combination with various barrels and metering valves, it can be used in a wide range of systems.
In the barrel system, the 55D series has a digital three-digit dispensing timer, which allows for finer dosing time settings and easier standardization.

With a discharge input signal holding circuit.
Discharge end signal output is standard equipment.
The solenoid valve high-speed operation circuit enables stable discharge from a small amount.
――By adopting a stainless steel chassis, it is resistant to dirt such as adhesives and can be kept clean forever.
From low viscosity materials such as water to high viscosity materials, it is possible to discharge from 0.0001cc/shot to any large amount.
By combining with a discharge valve, it can be used for a wide range of systems.
You can check the discharge by pressing the test switch on the panel.
The discharge timer can be set digitally. (Standard 0.01 ~ 9.99 seconds)
The timer range can be increased by one digit by switching the internal switch. ( Max. 0.1 ~ 99.9 seconds)

Control method	Pneumatic – Electronic Control
Pressure setting range	0.01 ～ 0.7MPa
power	AC100V or AC200~240V±10% 50/60Hz
Power consumption	7VA or less (at 100V AC)
Mode of operation	Timer mode (quantitative discharge)
	Free mode (continuous discharge)
	Switching
Timer	0.01~9.99 sec (digital setting)
Operating ability	400 times/min
External dimensions	180（W）×170（D）×81（H）mm
Weight	1.9kg
Vacuum mechanism	－
End of discharge signal (relay output)	MAX 125V, MAX 1A, MAX 30VA
Standard Accessories	Power cord, foot switch (FSO1) or metal outlet (MC1604P)
